14/12T-G High Chromium Alloy Gravel Sand Pump
Model No. 14/12T-G
Outlet Diameter: 300 mm
Speed: 300-700 r/min
Capacity: 700-2700 m³/h
Head:8-70 m
Efficiency: 65%
Power:1200 KW Max.
Gravel Sand Pump Applications:
Slag Granulation
Suction Hopper Dredging
Dredging
Barge Loading
Sand Reclamation
Sugar Beet
Materials of the Sand Gravel Pumps:
Volute Impeller Base Expeller Expeller Ring Shaft Sleeve Seals Standard High Chromium Alloy A05 A05 Cast Iron Chromium Alloy A05 SG Iron Natural Rubber Options A49 A07 A07 A49
G Model Sand Gravel Pump is designed for transferring large particles which Warman AH,HH could not do
.G sand pump transfers abrasive slurry which contain too big solid to be pumped by a common pump.
The advantages of the pumps are easy installation and operation,good performance of NPSH and abrasion resistance.
